1. 650m/1000m Long-Range Measurement: Available in 650m and 1000m versions, with a minimum measuring distance of 5m. Fast 0.3-1.0s range acquisition provides quick and reliable readings.
2. 7 Measurement Modes: Support Line Distance, Horizontal Distance, Vertical Distance, Height Difference, Speed Test, and Golf Mode with Slope Compensation and Flagpole Locking for versatile outdoor use.
3. Golf Slope Mode: The switchable slope compensation function accounts for elevation changes, helping provide more practical distance information on uneven golf courses.
4. Flagpole Lock with Vibration: In Golf Mode, the rangefinder can lock onto the closer flagpole among multiple targets. A target circle and vibration feedback confirm successful flagpole detection.
5. 6X Clear Optical View: Equipped with 6X magnification, 23.5mm objective lens, 15mm eye relief, and 7 degrees FOV, with +/-1-yard accuracy and 0.1-yard resolution for precise measurement.
Specifications
1. Measuring Range: 5-650m / 5-1000m
2. Minimum Range: 5m
3. Maximum Range: 650m / 1000m
4. Measurement Units: Yard (YD) / Meter (M)
5. Unit Switching: Long press the Mode button
6. Measurement Modes: Line Distance / Horizontal Distance / Vertical Distance / Height Difference / Speed Test / Golf
7. Golf Mode: Slope Compensation with Switch / Flagpole Locking with Vibration
8. Magnification: 6X
9. Objective Diameter: 23.5mm
10. Eye Relief: 15mm
11. Field of View: 7 degrees
12. Measuring Accuracy: +/-1 Yard
13. Measuring Resolution: 0.1 Yard
14. Range Acquisition Time: 0.3-1.0s
15. Inclination Range: +85 to ?85 degrees
16. Inclination Accuracy: +/-1 degree
17. Display Type: LCD
18. Power Source: Built-in Lithium Battery
19. Dimensions: 103 x 72 x 37mm
20. Weight: 130g
Golf Mode, Flagpole Locking:
Align the target marker with the desired flagpole, then long press the Measurement/Scan button. Slowly move the target marker across the flagpole or surrounding object. When the rangefinder detects the closer target, a circle appears around the flagpole and the device vibrates, confirming that the flagpole distance is displayed.
Precautions
1. This is a long-range laser rangefinder. The minimum measurable distance is 5m.
2. Do not measure through glass or other transparent materials, as laser reflections may affect measurement results.
3. Rain, fog, dust, and severe air pollution may interfere with laser transmission and affect measurement accuracy.
Specification:
| Package Weight |
| One Package Weight |
0.26kgs / 0.58lb |
| One Package Size |
16cm * 12cm * 7cm / 6.3inch * 4.72inch * 2.76inch |
| Carton Weight |
13.00kgs / 28.66lb |
| Carton Size |
46cm * 37cm * 32cm / 18.11inch * 14.57inch * 12.6inch |
| Loading Container |
20GP: 489 cartons * 40 pcs = 19560 pcs
40HQ: 1136 cartons * 40 pcs = 45440 pcs |
|
