MC4 Connector male female 30A 1000V Solar Panel Branch Series
MC4 Connector male female 30A 1000V Solar Panel Branch Series
MC4 Connector male female 30A 1000V Solar Panel Branch Series - Image 2
MC4 Connector male female 30A 1000V Solar Panel Branch Series - Image 3
MC4 Connector male female 30A 1000V Solar Panel Branch Series - Image 4
MC4 Connector male female 30A 1000V Solar Panel Branch Series - Image 5
MC4 Connector male female 30A 1000V Solar Panel Branch Series - Image 6
MC4 Connector male female 30A 1000V Solar Panel Branch Series - Image 7

MC4 Connector male female 30A 1000V Solar Panel Branch Series

₹300.00

Add to wishlist
Add to compare
SKU: TBD0513848 Category:
  • Model Number:EU
  • Connection:Plug In
  • Output Type:DC
  • Brand Name:ZOORUI
  • Usage:Electric Tool
  • Output voltage:DC1000V
  • Usage:solar
Specification
Product No:MC4
Rated Voltage TUV 1000V DC / UL 600V DC
Rating Current 20A-30A
Suitable cable cross sections 2.5mm2-6.0mm2 / 14AWG-10AWG
Pin dimension:4.0mm
Proof voltage:DC 8KV(1Min)
Pollution degree: 2
Protection class: Class II
Contact Material: Copper, tin-plated
Contact Resistance: 5mW
Connector Material: PPO
Degree of Protection: IP IP67(IEC 60529)
Withdrawal Force: 50N
Insertion Force: 50N
Temperature :-40-+85degree
Flame Class: UL94V – 0

Specification:
Package Weight
One Package Weight 0.03kgs / 0.07lb
One Package Size 8cm * 5cm * 2cm / 3.15inch * 1.97inch * 0.79inch
Qty per Carton 441
Carton Weight 15.00kgs / 33.07lb
Carton Size 60cm * 38cm * 15cm / 23.62inch * 14.96inch * 5.91inch
Loading Container 20GP: 779 cartons * 441 pcs = 343539 pcs
40HQ: 1810 cartons * 441 pcs = 798210 pcs
