1. Pixels: 13 million
2. Photographic chip: SC132GS
3. Photographic element size: 1/4 inch
4. Aperture: 2.0F
5. Resolution: 1280 x 1080 (per channel)
6. Focal length (BFL): 1.75mm
7. Field of view (FOV): 157.2° (D) 96.8° (H) 115.6° (V)
8. Maximum frame rate: 120FPS
9. Signal-to-noise ratio (SNR): 40dB
10. Baseline length: 80mm
11. Synchronization: supports external trigger and synchronization
12. Operating temperature: -20°C – 60°C
13. Packaging list: RDK Stereo Camera Module GS130W main unit x 1; 22-pin cable about 100mm x 2
Specification:
| Package Weight |
| One Package Weight |
0.13kgs / 0.30lb |
| One Package Size |
20cm * 6cm * 5cm / 7.87inch * 2.36inch * 1.97inch |
| Carton Weight |
11.00kgs / 24.25lb |
| Carton Size |
42cm * 37cm * 32cm / 16.54inch * 14.57inch * 12.6inch |
| Loading Container |
20GP: 536 cartons * 70 pcs = 37520 pcs
40HQ: 1244 cartons * 70 pcs = 87080 pcs |
|
